  3. GIGABYTE H610M H V3 DDR4 Motherboard / LGA1700 / Intel 14th-Gen Ready / DDR4 64GB Support / HDMI 4K / PCIe 4.0 / M.2 NVMe / USB 3.2 / mATX
Default

GIGABYTE H610M H V3 DDR4 Motherboard / LGA1700 / Intel 14th-Gen Ready / DDR4 64GB Support / HDMI 4K / PCIe 4.0 / M.2 NVMe / USB 3.2 / mATX

https://www.bluewavecomputers.in/web/image/product.template/4005/image_1920?unique=be70cea
₹ 6,300.00 ₹ 6,300.00 Tax Included

You can buy only one unit

Offer: 0.00%

This combination does not exist.

Accessories
Feature Description
Socket & CPU Support LGA1700 socket, supports Intel 14th/13th/12th Gen CPUs
Memory Supports DDR4 up to 64 GB, XMP, Dual Channel, ECC/Non-ECC DIMMs
Graphics Support HDMI 2.1 (4096x2160@60Hz), D-Sub (1920x1200@60Hz), HDCP 2.3 supported
Storage 1 x M.2 PCIe 3.0 x4/x2, 4 x SATA 6Gb/s
Expansion PCIe 4.0 x16 for GPU, PCIe 3.0 x1 for peripherals
Connectivity Realtek Gigabit LAN, USB 3.2 Gen 1, USB 2.0, PS/2, Audio

Contact Us

Terms and Conditions
A delivery charge will apply based on the pin code.
Shipping will take 3-5 business days.   ​

Share

Share

The Heart of Performance – LGA1700 Empowered

With its LGA1700 socket, this board welcomes Intel’s 14th, 13th, and 12th Gen Core™ processors, bringing modern speed and multitasking mastery to life.

Memory That Remembers – Up to 64GB DDR4 Might

Dual-channel DDR4 support up to 3200 MT/s ensures swift data flow. Whether ECC or non-ECC, your memory modules will perform with precision and reliability.

Visual Realms – HDMI 2.1 Brilliance

Onboard Intel® Graphics with HDMI 2.1 and D-Sub ports let you connect with ultra clarity — from 1080p classics to 4K future-ready displays.

Speed Within – Storage at Warp Drive

With one M.2 slot (PCIe 3.0 x4) and four SATA ports, your SSDs and HDDs can deliver speed and capacity for every gaming or productivity dream.

Connected and Cool – USB, LAN, and Fan Power

Realtek Gigabit LAN ensures stable networking. Paired with multiple USB 3.2 Gen 1 ports and customizable fan headers, you stay connected and cool under pressure.


Category Details
CPU Socket LGA1700
CPU Support 14th, 13th, 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
Chipset Intel® H610 Express Chipset
Memory Support DDR4 3200/3000/2933/2666/2400/2133 MT/s, 2 x DIMM up to 64 GB, ECC/Non-ECC Un-buffered DIMM support, XMP supported
Graphics Output 1 x D-Sub (1920x1200@60Hz), 1 x HDMI 2.1 (4096x2160@60Hz), HDCP 2.3 supported
Audio Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1 channels
LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Expansion Slots 1 x PCIe 4.0 x16 (CPU), 1 x PCIe 3.0 x1 (Chipset)
Storage Interfaces 1 x M.2 (PCIe 3.0 x4/x2), 4 x SATA 6Gb/s
USB Ports 2 x USB 3.2 Gen1 (rear), 2 x USB 3.2 Gen1 (internal), 4 x USB 2.0 (rear), 4 x USB 2.0 (internal)
Internal Headers USB 3.2 Gen 1, USB 2.0, RGB, SATA, M.2, Front Panel, Audio, TPM, Serial Port, Fan headers, Clear CMOS, Chassis intrusion, Speaker
Back Panel I/O PS/2 port, D-Sub, HDMI, 2 x USB 3.2 Gen1, 4 x USB 2.0, RJ-45, 3 x Audio Jacks
BIOS AMI UEFI BIOS, 128 Mbit flash
Form Factor Micro ATX (22.3 cm x 19.3 cm)
OS Support Windows 11 64-bit, Windows 10 64-bit
Software & Features APP Center (EasyTune, @BIOS, Smart Backup, System Info Viewer), Q-Flash, Norton Security (OEM), LAN bandwidth management
