TVSE LP-46 DLITE Plus Barcode Label Printer, 4 Inch, USB + Serial + ETHERNET More Printing with a Longer Ribbon Capacity of 300 M
Compact, advanced, and user-friendly barcode printer designed for all your high-resolution label and barcode printing needs. Perfect for industries such as manufacturing, warehousing, shipping, small offices, and retail, ensuring convenience and efficiency in every usage. Its space-saving design, quick installation process, and transparent window for easy monitoring make it an ideal choice for businesses looking to streamline their operations.
With USB, Serial, and Ethernet interfaces, increased storage, and high ribbon capacity, this printer effortlessly handles demanding label printing tasks.
FEATURES
| Print Method | Thermal Transfer |
| Resolution | 203 DPI |
| Print Width | 108 mm (Max.) |
| Print Speed | 152 mm/s (Max.) |
| Memory | SDRAM: 32 MB, Flash: 64 MB |
| Print Head Life | 50 Km |
| Sensor | Photoelectric Sensor |
| TPH Temperature Detection | Thermistor |
| TPH Position Detection | Microswitch |
| Interface | USB + Serial + Ethernet |
| CPU | 32-bit RISC MCP |
| 1D Barcodes | Code39, Code93, Codabar, Code128 (Subsets A, B, and C), EAN-13, EAN-8, UPC-A, UPC-E, UPC/EAN Extensions, Planet Code, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, G51 Data Bar (RSS) |
| 2D Barcodes | PDF417, MicroPDF417, QR Code, DataMatrix, MaxiCode, GS1 Composite |
| Character Enlargement/Rotation | Rotate (0°, 90°, 180°, 270°), Enlarge (1-10x) |
| Character Set | Vector fonts support stepless scaling; Built-in 7 dot matrix fonts and 1 vector font |
| Graphical | Support for user-defined fonts; Binary non-format bitmap, HEX, PCX, BMP, IMG |
| Paper Type | Continuous paper, marking paper, label paper, perforated paper |
| Paper Width | 118 mm (Max.) |
| Paper Roll OD (Max.) | 127 mm (5 inch) |
| Paper Roll ID | 25.4 mm (1 inch) / 38 mm (1.5 inch) |
| Paper Out Options | Tear off, Rewind, Peel off (optional), Cut (optional) |
| Paper Thickness | 0.06–0.25 mm |
| Ribbon Length | 300 m (Max.) |
| Ribbon ID | 12.7 mm / 25.4 mm |
| Button, Indicators | 1 button, 2 indicators |
| Input | 100–240V AC, 50–60Hz |
| Output | 24V DC, 2.5A |
| Operation Conditions | 5°C–45°C, 20%–90% RH (at 40°C) |
| Storage Conditions | -40°C–60°C, 20%–93% RH (at 40°C) |
| Dimensions | 280 mm (L) x 218 mm (W) x 180 mm (H) |
| Weight | About 2.3 kg |
