Gigabyte W480 Vision D (LGA 1200/Intel W480/ATX/Triple M.2/SATA 6Gb/s/USB 3.2 Gen 2/WiFi 6/Thunderbolt 3/ Multi-GPU Support/ECC Memory Support/Motherboard)

https://www.bluewavecomputers.in/web/image/product.template/3404/image_1920?unique=c0aa0f3
₹ 30,200.00 ₹ 30,200.00 Tax Included

You can buy only one unit

Offer: 0.00%

This combination does not exist.

Accessories
Feature Details
Model
W480 VISION D
CPU Support LGA1200 package: Intel® Xeon® W series processors, 10th Gen Intel® Core™ processors
Memory Capacity Up to 128 GB DDR4 (supports ECC and non-ECC memory), with support for extreme memory profiles (XMP)
Onboard Graphics Intel® Thunderbolt™ 3, HDMI port (max 4096x2160), and DisplayPort support
Networking 2.5GbE and Gigabit Ethernet LAN connections
Expansion Slots Multiple PCIe x16, x8, x4, x1 slots supporting CrossFire™ multi-GPU configurations
Storage Options 1 x M.2, 6 x SATA 6Gb/s, RAID support, Intel® Optane™ Memory Ready

Contact Us

Terms and Conditions
A delivery charge will apply based on the pin code.
Shipping will take 3-5 business days.   ​

Share

Share

The Powerhouse Processor

Built to support the robust Intel® Xeon® W series and 10th Gen Intel® Core™ processors, this motherboard ensures you never hit a performance bottleneck. With a vast range of supported CPUs, from the Xeon powerhouses to the versatile Core™ i7/i9, it's engineered for demanding applications.

Memory Mastery

Supporting up to 128 GB of DDR4 RAM and boasting speeds of up to 4400 MHz (O.C.), this motherboard is a memory beast. Whether you're building for high-end gaming, content creation, or workstation tasks, this board can handle it all.

Unstoppable Connectivity

Stay connected with lightning-fast Intel® 2.5GbE LAN and Intel® Wi-Fi 6 AX201, paired with Thunderbolt™ 3 ports for ultra-fast file transfers and display support. Multi-device connections have never been more seamless.

Storage Innovation

A flexible storage setup with 6 SATA 6Gb/s connectors, 3 M.2 slots, and Intel® Optane™ Memory compatibility. Whether you're working with SSDs or setting up RAID arrays, this motherboard has you covered.

Graphics Excellence

Integrated Intel® HD Graphics, coupled with dual Thunderbolt™ 3 ports and HDMI 1.4 support, offer rich visuals with up to 5120x2880 resolution. Gaming, streaming, and productivity all come together in stunning clarity.


Category Details
CPU Package LGA1200 package: Intel® Xeon® W series processors, 10th Gen Intel® Core™ processors/Intel® Pentium®/Celeron® processors
Chipset Intel® W480 Express Chipset
Memory Support Intel® Xeon® W-1290/W-1270 series processors/Intel® Core™ i9/i7 processors: DDR4 4400(O.C.) to 2133 MHz, 4 x DDR4 DIMM sockets, up to 128 GB
Onboard Graphics Intel® Thunderbolt™ 3 Controller: 2 x USB Type-C™ with DisplayPort, Intel® HD Graphics (1 x HDMI, max 4096x2160@30 Hz)
Audio Realtek® ALC1220-VB codec, DTS:X® Ultra, 2/4/5.1/7.1-channel audio, S/PDIF Out
LAN 1 x Intel® 2.5GbE LAN, 1 x Intel® GbE LAN
Wireless Communication Intel® Wi-Fi 6 AX201, Bluetooth 5, supports 11ax 160MHz wireless standard
Expansion Slots 1 x PCIe x16 slot (x16), 1 x PCIe x16 slot (x8), 1 x PCIe x16 slot (x4), 1 x PCIe x1 slot
Storage Interface 1 x M.2 connector, 6 x SATA 6Gb/s, RAID 0, 1, 5, 10, Intel® Optane™ Memory Ready
USB Ports 2 x USB Type-C™ (USB 3.2 Gen 2), 2 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
Internal Connectors 1 x 24-pin ATX, 1 x 8-pin ATX 12V, 4 x system fan headers, 2 x RGB headers, 1 x USB Type-C™ header
Back Panel Connectors 2 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 2 x RJ-45, HDMI, DisplayPort, Thunderbolt™ 3, Optical S/PDIF
I/O Controller iTE® I/O Controller Chip
H/W Monitoring Voltage detection, Temperature detection, Fan speed control
BIOS 1 x 256 Mbit flash, AMI UEFI BIOS
Unique Features APP Center, RGB Fusion, Fast Boot, Game Boost, USB DAC-UP 2, Q-Flash Plus
Bundled Software Norton® Internet Security (OEM version), cFosSpeed
Operating System Support Windows 10 64-bit
Form Factor ATX Form Factor (30.5cm x 24.4cm)
