Asus Prime H610M-Cs D4 Motherboard for Intel 12Th Gen Processors - Lga1700 Socket - ATX, Ddr4
Processor Compatibility
Supports Intel® LGA 1700 socket for 12th Gen Intel® Core™, Pentium® Gold, and Celeron® processors.
Designed for up to Intel® 65W CPUs.
Memory Support
2 x DIMM slots supporting up to 64GB of DDR4 memory.
Compatible with DDR4 speeds up to 3200 MHz.
Dual-channel memory architecture with Intel® Extreme Memory Profile (XMP) support.
Graphics Output
1 x VGA port.
1 x HDMI™ port supporting 4K@60Hz (HDMI 2.1).
Expansion Slots
1 x PCIe 4.0 x16 slot for graphics cards.
1 x PCIe 3.0 x1 slot for additional expansion.
Storage Options
1 x M.2 slot (Key M) supporting PCIe 3.0 x4 mode.
4 x SATA 6Gb/s ports for traditional storage drives.
Networking
Realtek 1Gb Ethernet for reliable wired connections.
USB Connectivity
Rear Ports: 2 x USB 3.2 Gen 1 (5G) ports, 4 x USB 2.0 ports.
Front Ports: 1 x USB 3.2 Gen 1 header (supports 2 ports), 1 x USB 2.0 header (supports 2 ports).
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC.
Features include jack-detection, multi-streaming, and premium audio capacitors.
Cooling and Power
1 x 4-pin CPU fan header and 1 x 4-pin chassis fan header.
Equipped with a PCH heatsink for efficient cooling.
Special Features
ASUS 5X Protection III: Includes DIGI+ VRM, LANGuard, and Overvoltage Protection.
UEFI BIOS with Advanced and EZ modes for easy system configuration.
Form Factor
Micro-ATX form factor, ideal for compact builds.
Features
| Specification | Details |
|---|---|
| Model | PRIME H610M-CS D4 |
| CPU | Intel® Socket LGA1700, supports Intel® Core™ 12th Gen Processors, Pentium® Gold, and Celeron® Processors |
| Chipset | Intel® H610 Chipset |
| Memory | - 2 x DIMM slots (Max. 64GB), DDR4 3200/3000/2933/2800/2666/2400/2133 MHz |
| - Dual-channel Memory Architecture | |
| - Supports Intel® Extreme Memory Profile (XMP) | |
| Graphics | - 1 x VGA port |
| - 1 x HDMI™ port (4K@60Hz, HDMI 2.1) | |
| Expansion Slots | - 1 x PCIe 4.0 x16 slot (CPU) |
| - 1 x PCIe 3.0 x1 slot (Chipset) | |
| Storage | - 1 x M.2 slot (Key M, PCIe 3.0 x4 mode, Type 2242/2260/2280) |
| - 4 x SATA 6Gb/s ports | |
| Ethernet | 1 x Realtek 1Gb Ethernet |
| USB | Rear USB (6 ports) |
| - 2 x USB 3.2 Gen 1 (Type-A, 5G) | |
| - 4 x USB 2.0 (Type-A) | |
| Front USB (4 ports) | |
| - 1 x USB 3.2 Gen 1 header (supports 2 USB 3.2 Gen 1 ports) | |
| - 1 x USB 2.0 header (supports 2 USB 2.0 ports) | |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC with audio shielding and premium capacitors |
| Back Panel I/O Ports | - 2 x USB 3.2 Gen 1, 4 x USB 2.0 |
| - 1 x VGA port, 1 x HDMI™ port | |
| - 1 x Realtek 1Gb Ethernet port | |
| - 3 x Audio jacks, 1 x PS/2 Keyboard port, 1 x PS/2 Mouse port | |
| Internal I/O Connectors | - 1 x 24-pin Main Power, 1 x 4-pin +12V Power |
| - 1 x M.2 slot, 4 x SATA 6Gb/s ports | |
| - USB headers, cooling headers, and miscellaneous connectors | |
| Special Features | - ASUS 5X Protection III: DIGI+ VRM, LANGuard, Overvoltage Protection, and SafeSlot Core |
| - ASUS Q-Design: Q-DIMM, Q-Slot | |
| - Aluminum Heatsink Design | |
| Software Features | - Armoury Crate, AI Suite 3 (EPU, DIGI+ VRM, PC Cleaner) |
| - Norton 360 (60-day trial), WinRAR | |
| - UEFI BIOS: ASUS CrashFree BIOS 3, ASUS EZ Flash 3 | |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | - 2 x SATA 6Gb/s cables |
| - 1 x I/O Shield, 1 x M.2 Anchor | |
| - 1 x User guide | |
| Operating System | Windows® 11, Windows® 10 64-bit |
| Form Factor | mATX (22.6 cm x 19.5 cm) |
